Factory Direct Supply Of German Din 3017 Stainless Steel Hose Clamps Of Model W2/W4
Product Description
Stable And Reliable, Installation Worry-Free
The exclusive 9mm and 12mm width options, along with the German "wolf-tooth" rolled edge design, effectively reduce friction during the locking process, prevent damage to the hose surface, and eliminate the risk of leakage.
It offers a torque higher than that of American clamps, combined with a unique extrusion tooth structure, ensuring stable clamping under high pressure and high vibration conditions, without cutting or sliding.
Flexible Adaptation And Wide Compatibility
The clamp diameter can be flexibly adjusted according to the pipe diameter, providing a variety of size ranges from 8mm to 50mm. One set can meet the diverse connection requirements of soft and hard pipes.
It is applicable to various media such as water, oil, steam and dust, and is widely used in various scenarios including automobiles, industry, ships and households.
Sturdy And Durable, Long-Lasting And Cost-Effective
DIN3017 Hose Clamps Made of high-quality stainless steel, it features excellent corrosion resistance and acid resistance, and has a long service life.
The design supports repeated disassembly, assembly and use, providing long-term stable sealing while also bringing you significant cost savings and environmental benefits.
Convenient Details, Humanistic Considerations
The Din3017 Germany Type Hose Clamp components are classified and stored in portable plastic boxes, which are convenient for storage, carrying and use, demonstrating meticulous attention to efficiency.
| Specification | Thickness(mm) | Bandwidth(mm) | Diameter Range(mm) | Mounting Torque(Nm ) | Material | Surface Finish |
| 201 Semi steel 8-12 | 0.65 | 9 | 8-12 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 10-16 | 0.65 | 9 | 10-16 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 13-19 | 0.65 | 9 | 13-19 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 12-20 | 0.65 | 9 | 12-20 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 12-22 | 0.65 | 9 | 12-22 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 16-25 | 0.65 | 9 | 16-25 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 16-27 | 0.65 | 9 | 16-27 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 19-29 | 0.65 | 9 | 19-29 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 20-32 | 0.65 | 9 | 20-32 | Load torque ≥8Nm | 304 Stainless steel | Polishing process |
| 201 Semi steel 21-38 | 0.65 | 9 | 21-38 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 25-40 | 0.65 | 9 | 25-40 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 30-45 | 0.65 | 9 | 30-45 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 32-50 | 0.65 | 9 | 32-50 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 40-60 | 0.65 | 9 | 40-60 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 50-70 | 0.65 | 9 | 50-70 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 60-80 | 0.65 | 9 | 60-80 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 70-90 | 0.65 | 9 | 70-90 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 80-100 | 0.65 | 9 | 80-100 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
| 201 Semi steel 90-110 | 0.65 | 9 | 90-110 | Load torque ≥8Nm | 201 Stainless steel | Polishing process |
Product Advantage
Reliable structure: DIN3017 Hose Clamps adopts an extruded gear structure and combines the design of curved edges on both sides, which not only enhances the protection of the hose but also improves the fixation effect, making it more suitable for hose use.
Firm anti-disengagement:Din3017 Germany Type Hose Clamp has an excellent holding effect, effectively preventing the hose from falling off or retracting under vibration or high pressure conditions, ensuring a sealed connection.
Durable and sturdy: Manufactured strictly to high standards, it is suitable for various industrial scenarios such as automobiles, machinery, and ships, and can withstand harsh environments.
Wide application: Covering various pipe diameters and industry requirements, including hydraulic, pneumatic and general industrial pipe connections.
Professional services: We offer one-on-one technical support and complete product information to assist customers in precise selection and usage.
Din3017 Germany Type Hose Clamp, featuring high performance, long service life and high adaptability, provides safe and stable hose connection solutions for various industries.
| Material | W1 | W2 | W4 | W5 |
| Hoop staps | Iron galvanize | 200ss/300ss | 200ss/300ss | 316 |
| Hoop shell | Iron galvanize | 200ss/300ss | 200ss/300ss | 316 |
| Screw | Iron galvanize | Iron galvanize | 200ss/300ss | 316 |
